Kerberos - Amplified Wireless Repeater

Amplified Wireless Repeater

The KET-RMB-210, together with the Gateway and the nodes with integrated Repeater functionality, provides the network infrastructure necessary for the correct transmission of data collected by wireless sensors.

The ZigBee™ standard guarantees high reliability and resistance to interference, while the high sensitivity of the radio module can reach distances of over 1000 m in free air.

The standard antenna connector supports 90° joint antennas or wired ones for placement outside the electrical panel.

Thanks to increased power, this device reduces the total number of nodes in the network.

GENERAL SPECIFICATIONS

Protection Range	IP50
Operative Temperature	-20 ÷ +60 °C

CASE

Dimensions	53,5 x 110 x 61 mm (W x H x D)
Mounting	Wall mounting or on DIN rail with supplied supports
Required DIN modules	3 DIN modules
Electric Board Type	Industrial
Material	Blend PC/ABS sel extinguishing UL94-VO

POWER SUPPLY

Supply Voltage	12 ÷ 24 VDC, 12 ÷ 20 VAC; 230 VAC with integrated power supply
Consumption	< 1.5 W @ 12 ÷ 20 VAC / < 1.5 W @ 12 ÷ 24 VDC / < 1.5 W @ 230 VAC
Connectors types	Screw terminal

RADIO MODULE

Supported Protocols	X-Monitor Protocol (X-MP) / IEEE 802.15.4 / ZigBee™ Pro 2.0
Radio Frequency	2.4 GHz ISM Band
Output Power	+3 ÷ +20 dBm
Sensitivity	-104 dBm
Antenna Type	RPSMA connector, 90° antenna supplied
Max Distance (Free Air)	Over 1000 m

FUNCTIONALITY

Radio Signal Indicator	Integrated (LinkQuality)
Output Power Adjustment	From local keyboard and remotely
Firmware Upgrade	Via radio
