Rotary Gas Flow Meters

Reliability, simple maintenance and an extended operating range while maintaining the measurement accuracy.

The KET-CGP-000 series rotary piston meters represent a valid alternative to those of the turbine type, being particularly recommended for systems that operate with frequent flow transients.

The body, made of aluminium, is strong, light and small in size. The rigid frontal support absorbs any forces resulting from the imperfect alignment of the pipes. The mechanical indicator and the impulse emission system are housed in a sealed anti-condensation drawer.

They are available in two versions: single (KET-CGP-000) or double case (KET-CGP-000.T) pistons. The TWIN variant has the advantage of eliminating the pulsation effect of the flow to the advantage of quiet operation.

Maintenance is simplified as the oil level indicators and lubrication connections are accessible from the front and the gauge can be installed in direct contact with any rear wall.

GENERAL SPECIFICATIONS
Protection Range IP67
Operative Temperature -30 ÷ +60 °C
DIGITAL OUTPUTS
Channels Pulse
GAS FLOW METER
Principle of Operation 4 pistons that move in opposition and that determine the quantity of gas that passes through the meter
Max Operating Pressure 1700 Kpa
Material Aluminium
Pistons Single or double case (.T)
Calibre G 10 ÷ 650
Tube Diameter Ø 40 ÷ 150 mm
Flanged Connections DIN PN 10/16 or ANSI 150
Standard Flow Direction Left - Right and High - Low
Weight From 10 to 53 Kg
CERTIFICATIONS
Referends Standard OIML R6, OIML R32, EN12480 class TC2, ANSI B109.3
Available Models
Codice Calibre Tube Diameter Range mc/h Wheelbase
KET-CGP-010.1 G 10 G 1½" 0,50 ÷ 16 121
KET-CGP-016.1 G 16 G 1½" 0,50 ÷ 25 121
KET-CGP-025.1 G 25 G 1½" 0,50 ÷ 40 121
KET-CGP-016.40 G 16 DN 40 (1½) 0,65 ÷ 25 171
KET-CGP-025.40 G 25 DN 40 (1½) 0,65 ÷ 40 171
KET-CGP-040.40 G 40 DN 40 (1½) 0,65 ÷ 65 171
KET-CGP-016.50 G 16 DN 50 (2”) 0,65 ÷ 25 171
KET-CGP-025.50 G 25 DN 50 (2”) 0,65 ÷ 40 171
KET-CGP-040.50 G 40 DN 50 (2”) 0,65 ÷ 65 171
KET-CGP-065.50 G 65 DN 50 (2”) 0,65 ÷ 100 171
KET-CGP-100.80 G 100 DN 80 (3”) 1,00 ÷ 160 171
KET-CGP-160.80 G 160 DN 80 (3”) 1,60 ÷ 250 241
KET-CGP-160.100 G 160 DN 100 (4”) 2,50 ÷ 250 241
KET-CGP-250.100 G 250 DN 100 (4”) 2,50 ÷ 400 241
