Flow Meters Turbine Gas Dresser

The KET-CGT-000 series of turbine meters are optimally suited for measuring of non-fiscal gas flow rates.

The characteristic of these meters is represented by the interchangeability of the cartridge internal, in which are integrated turbine, bearings and transmission gears, in agreement to standard EN 12261.

GENERAL SPECIFICATIONS
Protection Range IP67
Operative Temperature -25 ÷ +65 °C
DIGITAL OUTPUTS
Channels Pulse
GAS FLOW METER
Principle of Operation Gas velocity measurement
Max Project Pressure 20 bar
Precision Qmin = Q < Qt ± 3% & Qt = Q = Qmax ± 1,5%
Flanged Connections PN 16 o ANSI 150
Calibre G 40 ÷ 650
Tube Diameter Ø 50 ÷ 100 mm
Standard Flow Direction Horizontal (high - low on request)
Lubrication Pump Yes
Top With mechanical totaliser with dual pulse emitter BF
CERTIFICATIONS
Referends Standard OIML R6, OIML R32, EN12261, EEC
Available Models
Codice Calibre Tube Diameter Range mc/h Wheelbase
KET-CGT-040.50 G 40 DN 50 (2”) 13 ÷ 65 150
KET-CGT-065.50 G 65 DN 50 (2”) 10 ÷ 100 150
KET-CGT-100.50 G 100 DN 50 (2”) 16 ÷ 160 150
KET-CGT-100.80 G 100 DN 80 (3”) 16 ÷ 160 120
KET-CGT-160.80 G 160 DN 80 (3”) 25 ÷ 250 120
KET-CGT-160.100 G 160 DN 100 (4”) 25 ÷ 250 150
KET-CGT-250.80 G 250 DN 80 (3”) 20 ÷ 400 150
KET-CGT-250.100 G 250 DN 100 (4”) 20 ÷ 400 150
KET-CGT-400.80 G 400 DN 80 (3”) 32 ÷ 650 150
KET-CGT-400.100 G 400 DN 100 (4”) 32 ÷ 650 150
KET-CGT-650.100 G 650 DN 100 (4”) 50 ÷ 1000 150
