ModBUS RS485 module with 16 inputs - 8 digital outputs
The KET-IOD-100 is a module with 16 digital inputs with common negative, self-powered at 16 VDC, 8 of which can be set as 32-bit counters with a maximum frequency of 10 kHz. It also has 8 Mosfet digital outputs with common negative collectively powered by 5 - 30 Vdc. The digital outputs are available either from terminals or via an IDC10 connector to facilitate connection to external relays. The KET-IOD-100 has an RS485 serial communication interface with MODBUS-RTU protocol.
It requires the DIN-rail quick-mount bracket, Z-PC-DINAL1-35, equipped with removable screw connectors for power supply and 485 wiring.
GENERAL SPECIFICATIONS
| Protection Range | IP20 |
| Operative Temperature | -20 ÷ +65 °C |
| Storage Temperature | -20 ÷ +85 °C |
| Relative Humidity | MAX 85% not condensing |
CASE
| Dimensions | 35 x 102.5 x 111 mm (W x H x D) |
| Mounting | 35mm DIN rail IEC EN60715 |
| Material | Nylon 6 filled with 30% glass fibre, self-extinguishing class V0 |
POWER SUPPLY
| Supply Voltage | 10 ÷ 40 VDC; 19 ÷ 28 VAC |
| Consumption | < 2.5 W |
| Connectors types | Screw terminals on Z-PC-DINAL1-35 |
RS485 INTERFACE
| Supported Protocols | ModBUS RTU |
| Communication Rate | 2.4 ÷ 115.2 Kpbs |
| Isolation | 1,5 kVac (3 vie) |
| Connectors types | Screw terminals on Z-PC-DINAL1-35 |
DIGITAL INPUTS
| Channels | 16 (con negativo comune autoalimentati a 16 VDC) |
DIGITAL OUTPUTS
| Channels | 8 Mosfet type (open source) with common negative |
| Voltage Output | 5 ÷ 30 VDC |
CERTIFICATIONS
| Referends Standard | EN 61000-6-4, EN 64000-6-2, EN 61010-1 |
| Approvals | CE |
