Products | KET-WIR-100

Wireless infrared remote control for controlling air conditioners and heat pumps

KET-WIR-100 is an infrared remote control capable of controlling a wide range of air conditioners and heat pump systems. Using KET-WIR-100 it becomes simple to integrate cooling or heating elements in building energy management systems (BMS / BEMS). The .TH version includes digital temperature and relative humidity sensors.

The .TS version includes a convenient e-ink display and the user interface for setting the temperature set and other parameters useful for regulating the operation of the controlled device.

Management can be direct or intermediated by the supervision system.

Suitable for use in public environments supports keyboard lock and limitation of active functions.

GENERAL SPECIFICATIONS
Protection Range IP40
Operative Temperature -10 ÷ +60 °C
Storage Temperature -20 ÷ +70 °C
Relative Humidity MAX 85% not condensing
CASE
Dimensions 100 x 100 x 22.5 mm (W x H x D)
Mounting Panel mounting with supplied supports
Material ABS, self extinguishing: UL 94 V-O
POWER SUPPLY
Supply Voltage 5 ÷ 12 VDC
Connectors types Removable spring clamps
IR INTERFACE
Max distance 3 m
Learning mode Supported on .RX version
Supported devices Available on web site (use QR Code for quick access)
DIGITAL INPUTS
Channels 1 for drycontact
RADIO MODULE
Supported Protocols X-Monitor Protocol (X-MP) / IEEE 802.15.4
Radio Frequency 2.4 GHz
Output Power +20 dBm
Sensitivity -101 dBm
Antenna Type Internal
Max Distance (Free Air) Over 600 m
FUNCTIONALITY
Radio Signal Indicator Integrated (LinkQuality)
Output Power Adjustment From local menu and remotely
Firmware Upgrade Over The Air and via USB C connector
User menu Thermostat function with temperature summer / winter mode, comfort / saving / off mode, air speed setting, (only .TS version)
Support for public environment Anti-removal support, keyboard lock and active function limitation
TEMPERATURE SENSOR
Sensor Type NTC or digital (Only .TH version)
Measure Range -40 ÷ +123.8 °C
Precision ±0.4 ÷ 25 °C
Repeatability ±0.1 °C
Resolution ±0.01 °C
HUMIDITY SENSOR
Version Only .TH version
Measure Range 0 ÷ 100%RH
Precision ±3%RH from 20 to 80%RH
Repeatability ±0.03%RH
Resolution ±1%RH
Hysteresis ±1%RH
Long Period Stability <0.5%RH/year

Photo Code Description
Power Supply 230 VAC with output 12 VDC / 0.5 A output from junction box
KET-PSA-230.012.005.C

Power Supply 230 VAC with output 12 VDC / 0.5 A output from junction box


Photo Code Description
Advanced X-Monitor gateway with 3G/4G/NB-IoT/LTE-M modem and Wi-Fi™
KET-GZE-310

Advanced X-Monitor gateway with 3G/4G/NB-IoT/LTE-M modem and Wi-Fi™
