Wireless motion, temperature and lighting environmental sensor
KET-TLP-105 is an environmental sensor capable of detecting the movement of people within a radius of about 3-4 meters. The built-in double light sensor allows you to limit the lighting of lights only below a certain lighting threshold that can be set remotely. The temperature sensor completes the characteristics of the device.
The wireless transmission avoids the wiring costs by allowing the sensor to be installed even on the ceiling.
The dry contact input can be used for connecting door / window contacts, PIR sensors or control buttons.
Designed to easily integrate into supervision and energy management systems (BMS / BEMS). Designed for professional use, it supports firmware updating remotely or locally and rapid charging during service. Suitable for use in public environments supports keyboard lock.
| Protection Range | IP40 |
| Operative Temperature | -10 ÷ +60 °C |
| Storage Temperature | -15 ÷ +60 °C |
| Relative Humidity | MAX 80% not condensing |
| Dimensions | 100 x 100 x 22.5 mm (W x H x D) |
| Mounting | Wall mounted with supplied plate |
| Material | ABS, self extinguishing: UL 94 V-O |
| Supply Voltage | 12 VDC |
| Connectors types | Removable spring clamps |
| Channels | 1 for dry contact with detection time at contact variation of about 50ms. |
| Supported Protocols | X-Monitor Protocol (X-MP) / IEEE 802.15.4 |
| Radio Frequency | 2.4 GHz |
| Output Power | +3 ÷ +20 dBm |
| Sensitivity | -101 dBm |
| Antenna Type | 1 internal |
| Max Distance (Free Air) | Over 600 m |
| Radio Signal Indicator | Integrated (LinkQuality) |
| Output Power Adjustment | From local menu and remotely |
| Firmware Upgrade | via USB C connector |
| Support for public environment | Anti-removal support, keyboard lock |
| Sensor Type | NTC or digital (Only .TH version) |
| Measure Range | -40 ÷ +123.8 °C |
| Precision | ±0.4 ÷ 25 °C |
| Repeatability | ±0.1 °C |
| Resolution | ±0.01 °C |
| Version | Only .TH version |
| Measure Range | 0 ÷ 100%RH |
| Precision | ±3%RH from 20 to 80%RH |
| Repeatability | ±0.1%RH |
| Resolution | ±0.03%RH |
| Hysteresis | ±1%RH |
| Long Period Stability | <0.5%RH/year |
| Number of sensors | 2, on front and on top |
| Measure Range | 10 ÷ 1000 Lux |
| Response Curve | Similar to that of the human eye |
| Measurand | Up to 4 m; Recommended 0 ÷ 3.5 m |
| Viewing Angle | =100° cone angle, distance =4m |
