PoE People Counting Camera

The KET-CPA-200 is a sensor that uses the second generation ToF (Time of Flight) technology to accurately count people. This technology provides more accurate depth maps and longer detection distances, while maintaining excellent privacy protection. The advanced ToF technology, combined with an AI algorithm, enables the sensor to handle complex scenes and distinguish non-human objects with up to 99.8% accuracy. ln fact, the sensor is GDPR compliant. It only obtains in-depth images without involving personally identifiable information based on ToF technology, which protects at source.

The PoE power, it enables easy Ethernet connectivity. With easy installation, it is ideal for entrances or corridors of retail shops, shopping centres, offices, subways and other locations. Equipped with 4 GB flash memory to store one million count data locally and securely.



GENERAL SPECIFICATIONS
Protection Range IP40
Operative Temperature -20 ÷ +50 °C
Relative Humidity MAX 95% not condensing
CASE
Dimensions 180 x 26 x 72 mm (W x H x D)
Mounting Ceiling Mounting, < 3.5 m
POWER SUPPLY
Supply Voltage 802.3at PoE
Consumption Typical 9.4 W, max 23.8 W
DATALOGGER FUNCTION
Memory Type Flash 4 GB
Data Storage Capacity One million data
RS485 INTERFACE
Channels 1
Supported Protocols ModBUS RTU
Connectors types Screw terminal
ETHERNET INTERFACE
Supported Protocols HTTP, MQTT, NTP
Communication Rate 10/100 Mbps (PoE PD)
Connectors types 1 RJ45
PEOPLE COUNTING
Operating modes ToF (Time of Flight)
Field of view 98° horizontal, 80° verticali
Light beam 940 nm (invisible)
Accuracy <3.5 cm
Measurand 0.5 ÷ 3.5 m
Recognition rate Up to 99.8%
Special Functions Customized multiple counting lines, filter U-turns, bi-directional counting, children/adults differentiation, staff detection
