The KET-THL-210.S is a sensor designed for outdoor positioning thanks to the high degree of protection of the container and the temperature and relative humidity sensors protected from the weather, also integrates a light sensor for a complete environmental monitoring.
It communicates with PLC/SCADA through the RS485 ModBUS RTU interface.
The KET-THL-210.S is powered by 9 ÷ 16 VDC.
| Protection Range | IP65 |
| Operative Temperature | -20 ÷ +70 °C |
| Dimensions | 80 x 81 x 56 mm (W x H x D) |
| Mounting | Wall mounting |
| Material | UV resistant polycarbonate, Self-extinguishing: UL 94 V2-HB |
| Supply Voltage | 9 ÷ 16 VDC |
| Supported Protocols | ModBUS RTU |
| Isolation | Isolated |
| Measure Range | -40 ÷ +123.8 °C |
| Precision | ±0.4 ÷ 25 °C |
| Repeatability | ±0.1 °C |
| Resolution | ±0.01 °C |
| Measure Range | 0 ÷ 100%RH |
| Precision | ±3%RH from 20 to 80%RH |
| Repeatability | ±0.1%RH |
| Resolution | ±0.03%RH |
| Hysteresis | ±1%RH |
| Long Period Stability | <0.5%RH/year |
| Measure Range | 10 ÷ 1000 Lux |
| Response Curve | Similar to that of the human eye |
| Photo | Code | Description |
|---|---|---|
|
KET-GZE-310 |
Advanced X-Monitor gateway with 3G/4G/NB-IoT/LTE-M modem and Wi-Fi™ |
|
KET-RMB-211 |
Master ModBUS RTU Wireless |
|
KET-RMB-211.CN.32 |
Climate control interface for Mitsubishi systems |
| Photo | Code | Description |
|---|---|---|
|
KET-THL-200.S |
Wireless Temperature, Humidity and Light sensor for outdoor use |
|
KET-SLE-100 |
Wireless outdoor brightness sensor |
