Relay for deactivation of loads with 0-10 V input

The KET-REL-010 is a relay that allows the deactivation of the load when using an analog interface 0 ÷ 10 V.

It deactivates the load when the control voltage drops below the value of about 0.8 V and reactivates it when the voltage exceeds the value of about 0.9 V in this way, using a control device such as the KET-DIM-100 it is possible to simultaneously control a 1-10 V output and switch off the load.

The compact measures allow its use inside junction boxes, ceiling lights, fans, converters, etc.

GENERAL SPECIFICATIONS
Protection Range IP40
Operative Temperature -15 ÷ +60 °C
CASE
Dimensions 44 x 44 x 25 mm (W x H x D)
Mounting Directly on the device
Material Black plastic, self extinguishing: UL 94 V-O
POWER SUPPLY
Supply Voltage 230 VAC with integrated power supply (50-60 Hz)
Consumption 1.5 VA
Connectors types Device supplied with pre-skinned cable terminals
RELE' OUTPUTS
Channels 1 x Switching loads on and off
Maximum Rated Current 8 A
Isolation Class II

Photo Code Description
Wireless control module with 0-10 V output
KET-DIM-100

Wireless control module with 0-10 V output
