Hall effect openable current sensor with 10 A measuring range
The KET-SHA-001.21 is part of a series of newly developed open-loop Hall current sensors that can be used to detect DC, AC current signals, even high frequency, pulse and irregular current signals.
Isolated on the primary and secondary side, it ensures maximum electrical safety.
Equipped with 2 m long connection cable, with RJ12 connector, through which power is supplied from a single external DC and stabilized voltage.
GENERAL SPECIFICATIONS
| Operative Temperature | -25 ÷ +80 °C |
| Storage Temperature | -40 ÷ +85 °C |
CASE
| Dimensions | 60 x 61 x 20.5 mm (W x H x D) |
| Cable Diameter | Max 21 mm |
| Material | Self extinguishing: UL 94 V-O |
POWER SUPPLY
| Supply Voltage | +5 (±1%)VDC |
| Consumption | <=15 mA |
| Connectors types | RJ12 (6P4C) |
CURRENT SENSOR
| Sensor Type | Hall effect openable sensor |
| Current Range | ±10 A |
| Internal Resistance | >=10 kOhm |
| Precision | <=2 .0% ( T=25°C VC=±15V) |
| Linearity | <=2 .0% ( T=25°C) |
| Hi Pot Test | 3.0 kV/Min |
CERTIFICATIONS
| Referends Standard | RoHS Compliant |
