Amplified Wireless Repeater

The KET-RMB-220, together with the nodes with integrated repeater functionality and the Gateway, provides the network infrastructure necessary for the proper transmission of data collected by wireless sensors.

The X-Monitor technology guarantees high reliability and resistance to interference, while the excellent sensibility of the radio module allows to reach distances of more than 1000 m in free air.

Standard antenna connector, supports antennas with 90° joint.

Thanks to the increased power, this device reduces the overall number of nodes in the network.

GENERAL SPECIFICATIONS

Protection Range	IP50
Operative Temperature	-20 ÷ +60 °C

CASE

Dimensions	100 x 45 x 30 mm (W x H x D)
Mounting	Wall mounting
Material	Black nylon

POWER SUPPLY

Supply Voltage	230 VAC with integrated power supply (50-60 Hz)
Consumption	< 1.5 W @ 230 VAC
Connectors types	Device supplied with pre-skinned cable terminals

RADIO MODULE

Supported Protocols	X-Monitor Protocol (X-MP) / IEEE 802.15.4
Radio Frequency	2.4 GHz ISM Band
Output Power	+3 ÷ +20 dBm
Sensitivity	-104 dBm
Antenna Type	RPSMA connector, 90° antenna supplied
Max Distance (Free Air)	Over 1000 m

FUNCTIONALITY

Radio Signal Indicator	Integrated (LinkQuality)
Output Power Adjustment	From local keyboard and remotely
Firmware Upgrade	Via radio

Photo	Code	Description
	KET-ANT-203	2.4 GHz small antenna with cable 40 cm and RPSMA connector
	KET-ANT-300.S	2.4 GHz Omnidirectional fiberglass antenna with 5 dBi gain
	KET-ANT-400.S	2.4 GHz Omnidirectional fiberglass antenna with 9 dBi gain
	KET-ANT-204	2.4 GHz small antenna with cable 100 cm and RPSMA connector
